歐美晶振
- 產品型號：46009248
- 晶振頻率：25.970040560MHz
- 晶振尺寸：3.2*2.5*0.9mm
- 產品應用： Geyer晶振,KX-7T石英諧振器,無源晶振,12.60212晶振,3225貼片晶振,石英晶振,四腳封裝晶振,SMD晶體,頻率25.970040560MHz,負載8pF,頻率容差30ppm,工作溫度-40~85°C,輕薄小晶振,高品質晶振,高可靠性晶振,電信交換機晶振,...
-
12.60212|25.970040560MHz|8pF|Geyer晶振
12.60212|25.970040560MHz|8pF|Geyer晶振,Geyer晶振,KX-7T石英諧振器,無源晶振,12.60212晶振,3225貼片晶振,石英晶振,四腳封裝晶振,SMD晶體,頻率25.970040560MHz,負載8pF,頻率容差30ppm,工作溫度-40~85°C,輕薄小晶振,高品質晶振,高可靠性晶振,電信交換機晶振,USB存儲設備晶振,數據中心晶振,智能家居晶振.
12.60212|25.970040560MHz|8pF|Geyer晶振規格表
| part no. | 12.60212 |
| model | KX-7T |
| frequency range | 25.970040560MHz |
|
mode |
fundamental |
| operating temperature | -40~+85℃ |
| frequency tolerance at +25°C | 土30 ppm |
| temperature tolerance |
土50 ppm
|
| storage temperature range | -55°C~+125℃ |
| load capacitance CL | 8 pF |
| shunt capacitance C0 typ. | 3.0 pF |
| series resistance R1 (ESR) max. | 60 Ohm |
| aging at +25°℃ (first year) max. | ±2 ppm |
| drive level | 200 μW max. |
| contents of reel | 1000 pcs. |
.jpg)
12.60212|25.970040560MHz|8pF|Geyer晶振尺寸圖
.jpg)
